135 Ton, 4.73 Oz., Haitian VEIII 1200/300 Injection Molding Machine
135 Ton, 4.73 Oz., Haitian VEIII 1200/300 Injection Molding Machine
Available quantity:1
or
Call +1 508-792-4305
Specifications
| Manufacturer | Haitian |
| Model | VEIII 1200/300 |
| Year | 2023 |
| Condition | New |
| Stock Number | 14109 |
| Model | VE1200III/300 B-Screw |
| US Tonnage | 135 |
| Shot Size (oz. of PS) | 4.73 |
| Screw Diameter | 36mm |
| Platen Size (in.) | 27.17 x 27.17 |
| Tiebar Spacing (HxV) in. | 18.5 x 18.5 |
| Max Mold Height (in.) | 19 |
| Min Mold Height (in.) | 6 |
| Opening Stroke (in.) | 14 |
| Open Daylight (in.) | 33 |
| Ejector Stroke (in.) | 4 |
| Control | KEBA |
| Voltage | 460V/3P/60Hz |
