337 Ton, 23.56 Oz., Haitian Zhafir VE 3000/1400 Injection Molding Machine (2010)
337 Ton, 23.56 Oz., Haitian Zhafir VE 3000/1400 Injection Molding Machine (2010)
Available quantity:1
or
Call +1 508-792-4305
Specifications
| Manufacturer | Haitian |
| Model | VE 3000/1400 |
| Year | 2010 |
| Condition | Used |
| Stock Number | 13982 |
| Model | VE 3000/1400 B-Screw |
| US Tonnage | 337 |
| Shot Size (oz. of PS) | 23.56 |
| Screw Diameter | 60mm |
| Platen Size (in.) | 39.37 x 37.40 |
| Tiebar Spacing (HxV) in. | 26.38 x 24.41 |
| Max Mold Height (in.) | 25.20 |
| Min Mold Height (in.) | 9.45 |
| Opening Stroke (in.) | 48.82 |
| Ejector Stroke (in.) | 5.91 |
| Toggle Stroke (in.) | 23.62 |
| Voltage | 460V/3P/60Hz |
