67 Ton, 4.89 Oz., Haitian MAIII 600/280 Injection Molding Machine (2023)

67 Ton, 4.89 Oz., Haitian MAIII 600/280 Injection Molding Machine (2023)

Available quantity:1

or
Call +1 508-792-4305

Specifications

ManufacturerHaitian
ModelMAIII 600/280
Year2023
ConditionNew
Stock Number13774
ModelMAIII 600/280 B-Screw
US Tonnage67
Shot Size (oz. of PS)4.89
Screw Diameter36 mm
Platen Size (in.)18.5 x 18.5
Tiebar Spacing (HxV) in.12.2 x 12.2
Max Mold Height (in.)12.99
Min Mold Height (in.)4.72
Opening Stroke (in.)10.63
Open Daylight (in.)23.62
Ejector Stroke (in.)2.76
Voltage460V/3P/60Hz

Included Options

Core Pull, Air Blast, Robot Interface
