214 Ton, 8.09 Oz., Haitian ZEIII 1900F/640h Injection Molding Machine (2020) - LAB
No longer available
214 Ton, 8.09 Oz., Haitian ZEIII 1900F/640h Injection Molding Machine (2020) - LAB
Available quantity:1
Specifications
| Manufacturer | Haitian |
| Model | ZE III F 1900/640 High-Speed |
| Year | 2020 |
| Condition | Used |
| Stock Number | 11891 |
| Model | ZE III F 1900/640H |
| US Tonnage | 214 |
| Shot Size (oz.) | 8.09 |
| Screw Diameter | 40 mm |
| Platen Size (in.) | 33.07 x 33.07 |
| Tie Bar Spacing (in.) | 22.44 x 22.44 |
| Max Mold Height (in.) | 21.65 |
| Min Mold Height (in.) | 7.87 |
| Clamp Stroke (in.) | 18.50 |
| Max Daylight (in.) | 40.16 |
| Ejector Stroke (in.) | 5.91 |
| Voltage | 460/3/60 |
| Control | Sigmatek |
| Includes | 100 mm Increased Die Height, Core Pull, Air Blast, Robot Interface, Pneumatic Valve Gate, Hydraulic Valve Gate, RJG, Expanded I/O, Euromap 73, OPC Communication |
